Side bending and Top lighting
Lumileds 2835LED inside
Dual-color silicone extrusion
UV and yellowish resistant
IP67 and salt-mist proof
L70B50 > 50,000hrs
UL 94 V-0
Easy installation and re-connect accessories
Min. bending radius 20cm
Neon tube light source
Building and sign outline lighting
General and cove lighting
Ships, boats and trucks outline lighting
Bathroom, spa room lighting
Notes:
1.Unit: mm
| Ambient temperature range (Ta on free air) | -40℃ ~ +65℃ |
| Operating (case) temperature range (Tc) | -40℃ ~ +65℃ |
| Storage temperature range | -40℃ ~ +85℃ |
| ESD protection | Contact 4KV,Air 8KV |
| IP rating | IP67 |
| Item | NH2424S |
|---|---|
| Supply voltage range | 24.0±1.0 VDC |
| Supply Current range (per meter) | Typ.1000mA |
| Power range (per meter) | Typ. 24W |
| ESD protection | Contact 4KV, Air 8KV |
| Max. length for single end power-in | 10 meters |
| Max. length for two ends power-in | 15 meters |
| Cutting unit length | 10cm |
| Part No. | Colorimetric Parameters | Product Flux | ||
|---|---|---|---|---|
| Color | Value | Typ.Lm/mtr | CRI | |
| NH2424S | White | 6500K | 1560 lm/m | 80 |
| White | 5000K | 1560 lm/m | 80 | |
| White | 4000K | 1560 lm/m | 80 | |
| White | 3000K | 1450 lm/m | 80 | |
| White | 2700K | 1450 lm/m | 80 | |
Side feeder
Bottom feeder
End feeder
