Side bending and Top lighting
Enhanced SMT LED inside
Dual-color silicone extrusion
UV and yellowish resistant
IP67 and salt-mist proof
L70B50 > 50,000hrs
UL 94 V-0
Easy installation and re-connect accessories
Min. bending radius 3cm
Neon tube light source
Building and sign outline lighting
General and cove lighting
Ships, boats and trucks outline lighting
Bathroom, spa room lighting
Notes:
1.Unit: mm
| Ambient temperature range (Ta on free air) | -40℃ ~ +55℃ |
| Operating (case) temperature range (Tc) | -40℃ ~ +65℃ |
| Storage temperature range | -40℃ ~ +85℃ |
| IP rating | IP67/ |
| Item | NH0712C6 | NH0712C3 |
|---|---|---|
| Supply voltage range | 24.0±1.0 VDC | 24.0±1.0 VDC |
| Supply Current range (per meter) | Typ.375 mA | Typ.750 mA |
| Power range (per meter) | Typ.9W | Typ.9W |
| ESD protection | Contact 4KV, Air 8KV | Contact 4KV, Air 8KV |
| Max. length for single end power-in | 5 meters | 5 meters |
| Max. length for two ends power-in | 7.5 meters | 10 meters |
| Cutting unit length(mm) | 50 for W/R/G/B/Y/O products | 50 for W/R/G/B/Y/O products |
| Part No. | Colorimetric Parameters | Product Flux | ||
|---|---|---|---|---|
| Color | Value | Typ.Flux | CRI | |
| NH0712C | White | 6500K | 330 lm/m | Ra.80 |
| White | 5500K | 330 lm/m | Ra.80 | |
| White | 4300K | 300 lm/m | Ra.80 | |
| White | 3000K | 300 lm/m | Ra.80 | |
| Red lighting and white jacket | 631nm | 95 lm/m | N.A | |
| Blue lighting and white jacket | 525nm | 232 lm/m | N.A | |
| Green lighting and white jacket | 463nm | 56 lm/m | N.A | |
| Red lighting and white jacket | 631nm | 60 lm/m | N.A | |
| Blue lighting and white jacket | 525nm | TBD | N.A | |
| Green lighting and white jacket | 463nm | 25 lm/m | N.A | |
| Yellow lighting and white jacket | 591nm | 175 lm/m | N.A | |
| Orange lighting and white jacket | TBD | TBD | N.A | |
